Electric Height Adjustable Standing Desk Frame - Smart Stand Apex

You already have a desktop you love but it would be so much better if you converted it into a standing desk.

Don't worry! We've got you covered.

Choose the frame only option from Smart Stand and create a unique, high-quality standing desk that's perfect for you.

The Smart Stand Apex frame comes in our Raw Steel colour with a 10 year guarantee and next day delivery in the UK.

Technical Specifications:

• Frame Width Adjustment 1150 - 1740mm
• Height Range (Inc. 25mm Top) 615 - 1275mm (± 5mm)
• Stroke (Difference between lowest and highest height) 660mm
• Side Bracket Depth 575mm
• Foot Depth 590mm (front to back leg)
• Max Even Load Capacity 100kg
• Total Frame Weight 29kg
• Operational Life 10,000 cycles at full rated load
• Voltage 230V AC Input, 24V DC operation
• Operational Speed 40mm per second
• Standby Power <0.3W
• Max Operational Power 300W
• Programmable Min/Max Height Yes
• Duty Cycle 10% - 2mins on, 18mins off
• Noise Level <42 dB
• Anti-Collision Yes

Packaging

• Frame Package Size
  • Package 1 = 840 x 380 x 120mm (x1)
  • Package 2 = 160 x 160 x 100 (x1)
• Frame Package Weight 31kg (total)
• Frame Package Quantity 2 (total)

Installation

• Build Time (per unit) 20 - 30 mins
• Suitable for self assembly

Compliance

• UKCA and CE Conformity, Machine Directive 2006/42/EC,
• EMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EC, REACH, WEEE, RoHS 3 2015/863, EN 527-1:2011 Type A, EN 527-2:2016 ISO 21016, UL 962 ETL Listed
